King Bearings Connecting Rod Bearing Set CR807HPN; HP Series Performance Standard for 1968 to 2003 Chevy 262 to 400
$66.34
This item ships free with qualifying orders of $150 or more.
See our shipping policy for more details.
Details
- 24% Stronger Overlay Achieving 18.1HV
- 17% Greater Fatigue Resistance
- Unique Geometric Design Maximizes Surface Load Area
- Bull’s Eye Wall Tolerance™ Ensures Perfect Oil Clearance in Every Set
- 450°F heat threshold for superior protection against friction and overheating
- Mains are 3/4 grooved for improved oiling to the rod journals
- 450°F heat threshold for superior protection against friction and overheating
- Mains are 3/4 grooved for improved oiling to the rod journals
Specifications
- Engine Connecting Rod Bearing Set Model or Series:
- HP Series
- Year:
- 1968 to 2003
- Make:
- Chevy
- Engine:
- 262 to 400
- Bearing Undersize:
- Standard
- Usage:
- Performance
- Construction:
- Bi-Metal
- Backing Layer Material:
- Steel
- Bearing Lining or Intermediate Material:
- Aluminum
- Overlay Material:
- None
- Coated:
- No
- Chamfered:
- No
- Narrowed:
- Yes
- Grooved:
- No
- Bearing Width:
- 0.791 in.
- Standard Bearing Thickness (Without O/S):
- 0.062 in.
- Standard Crank Pin Diameter (Without O/S):
- 2.100 in.
- Standard Housing Diameter (Without O/S):
- 2.225 in.
- Includes Dowel Pin Hole:
- No
- Notes:
- Large Journal
- Quantity:
- Sold As Set (8/pkg)
